High Quality Fast Top Speed Splitter and Warper in One Factory Direct New Mother Yarn Warping Machine for Manufacturing Plant

High Quality Fast Top Speed Splitter and Warper in One Factory Direct New Mother Yarn Warping Machine for Manufacturing Plant

  • Overview
  • Inquiry
  • Related Products

ProfixM


Introducing the High Quality Fast Top Speed Splitter and Warper in One Factory Direct New Mother Yarn Warping Machine for Manufacturing Plant. This new and innovative product is perfect for manufacturing plants that are looking for a durable and efficient mother yarn warping machine.


The ProfixM machine is a powerful tool for any factory or manufacturing plant. It is designed to split and warp yarn quickly and with consistency, making it the perfect choice for high-volume production. Additionally, it is built to last with high-quality materials, so you can rely on it to keep performing day after day.


One of the most impressive features of the profixM is its fast top speed. It is capable of working at high speeds without sacrificing accuracy or quality. This means you can produce more product in less time, which can increase your overall output and profit.


Another benefit of the ProfixM is that it is a splitter and warper in one machine. This means that you don't have to purchase separate equipment and it saves space in your factory or manufacturing plant. This helps streamline your production process and reduces the need for additional machines.


The ProfixM is also incredibly easy to use. It has a user-friendly interface that makes it simple to operate, even for those who are new to mother yarn warping machines. The machine is also low maintenance and easy to clean, which saves you time and reduces the risk of downtime due to equipment issues.


the ProfixM High Quality Fast Top Speed Splitter and Warper in One Factory Direct New Mother Yarn Warping Machine for Manufacturing Plant is a top-of-the-line choice for any factory or manufacturing plant looking for a reliable, efficient, and durable mother yarn warping machine. With its fast top speed, splitter and warper capabilities, ease of use, and low maintenance, the ProfixM is sure to exceed your expectations and help you increase your production and profit. Invest in the ProfixM today and experience the difference it can make in your manufacturing process.


Specification
item
value
Applicable Industries
Manufacturing Plant
Name
PF-4 SECTIONAL MOTHER YARN SPLITTING WARPING MACHINE
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
New Product 2023
Warranty of core components
1 Year
Place of Origin
China, Jiangsu
Machine Type
WARPING MACHINE
Material Capabilities
NYLON/ POLYESTER FDY/ DTY MOTHER YARN
Condition
New
Weight (KG)
13500
Yarn Usage
1t/day 240D/12F SD
Warping max speed
600m/min ON 240/12 SD NYLON MOTHER YARN
warping servo moto
7.5kw
beam moto
15kw
warp beam max speed
180m/min
displacement servo
1.5kw
Front roller servo
5.5kw
Back roller servo
4.5kw
A warp knitting machine is a mechanical device used for weaving warp yarns, which plays an important role in the textile industry
Definition and Function
The warp knitting machine is mainly used to tear off the raw pulp from a large number of single strands of yarn or blended fabrics, straighten them, and then rewire them on the warp knitting drum to form a "warp knitting". This process is crucial for ensuring the quality of the fabric and the smooth progress of subsequent weaving
structure
The warping machine is mainly composed of a frame, a yarn storage rack, warping rollers, tension rollers, correction devices, transmission systems, etc
Working principle
The warp yarn is led out from the yarn storage rack, passes through the guide roller and tension roller, and enters the warping roller; The warp roller shapes the warp yarn into sheets according to a certain length and width; The correction device ensures that the warp yarn pieces are arranged neatly; Finally, the warp yarn passes through the transmission system to complete the warping process
Advantages and Applications
1) The warping machine has the characteristics of high efficiency, stability, and reliability, which can greatly improve the production efficiency of the textile industry. 2) Its high precision and consistency ensure the quality of the fabric, making it more neat and uniform. 3) The warping machine is widely used in the textile industry and is one of the very important production equipment in textile factories
